IMS 841 Portable Screener

PRODUCT TYPE: Screener

VENDOR: IMS

CLICK HERE to download brochure
CLICK HERE to view video

DESCRIPTION

Road Portable 841 wheeled mobile screens, are specifically targeted at the developing and contractor markets, where mobility and quick set up are essential.  The 4 bearing screens are designed to suit various material types both in dry and wet screening applications.

    Features & Benefits
    • 7 Yd Hopper with Variable Speed Belt Feeder and Remote Tipping Grid
    • Maximum Feed Size 6”
    • 8’ x 4’ Double Deck 4 Bearing screen with end tensioned meshes
    • Capacity up to 250 tph
    • Diesel Hydraulic Drive to latest emission standards
    • 50hp / 37kw engine
    • Fifth Wheel Towing with transport wheels and axle
    • Site Towbar for localized movement with site equipment
    Options
    • Single Shaft Shredder with hammers or flails
    • Braked Axle
    • Light Board
    • Rinse Bars and Rubber Lined Sandbox
    • 3 Deck Screen
    • Electric drive

    Specification Table
                                   841 Wheel
    Weight  20,000lbs
    Transport width 7' 3"
    Transport length 53'
    Transport height 12' 6"
    Working width 7' 3"
    Working length 57'
    Working height 16’ 6’’



    ** All information subject to machine configurations & specifications ordered.

    ** Powerscreen reserves the right to change specifications without prior notice.
