Cobra 290R Recirculation Impact Crusher

PRODUCT TYPE: Impact Crusher

VENDOR: Terex Evoquip

CLICK HERE to download brochure
CLICK HERE to view video
DESCRIPTION

The Cobra 290R is a versatile and easy to use Track Mounted Impact crusher that can operate in the most demanding of applications such as Reinforced Concrete, Recycled Asphalt, Construction and Demolition waste and Natural Rock. The integrated Afterscreen system on the Cobra 290R ensures the required product specification is achieved with oversize material either being recirculated back to the Crusher or else stockpiled.
    Features & Benefits
    • Quick set up time typically under 15 minutes
    • CSS adjusted remotely
    • 41” x 31” Crusher inlet
    • 41" x 41.5” Rotor
    • Hydraulic adjust and overload as standard
    • Stepped self-cleaning grizzly
    • Grizzly bypass and fines chute
    • Modular product conveyor with raise / lower facility
    • CAT C7.1 315hp engine
    • Fuel efficient Direct drive with HPTO clutch
    • Variable chamber speed
    • Side tensioned Single deck post screen
    Specification Table
    Weight 75,398lbs
    Transport length 48’5”
    Transport width 9’6”
    Transport height 10’4”
    Capacity 290US tph
    Max lump size 30" diagonally (depending on material type)
    Screenbox size 9' x 6'

    FULL SPECIFICATION BROCHURE

    * All information subject to machine configurations & specifications ordered.

    ** Terex Evoquip reserves the right to change specifications without prior notice.
