Powerscreen XA750S

PRODUCT TYPE: Jaw Crusher

VENDOR: Powerscreen

CLICK HERE to download brochure
CLICK HERE to view video

DESCRIPTION

The Powerscreen® XA750S jaw crusher is one of the most advanced and efficient tracked crushing plants on the market for large scale operators. The XA750S is capable of producing high volumes of excellently shaped product. Key features include an unrestricted feed opening which maintains high production capacities and prevents bridging, a hydraulic closed side setting adjustment system and a hydraulic draw back rod retention system. User benefits include hydraulically adjustable product conveyor for ease of transport and low running costs associated with the direct drive crusher system.

    FULL SPECIFICATION BROCHURE

    Features & Benefits
    • High output and excellent reduction capabilities
    • Excellent under crusher access with a hydraulic tilting conveyor system
    • Hydraulic folding hopper with over centre struts and wedgelock system
    • Hydraulic draw back mechanism keeps jaw stock in tension on toggle plate
    • Modular product conveyor with raise/lower facility to aid rebar clearance, transport & maintenance
    • Modular design heavy duty chassis and track frame, which can be dismantled for transport (hopper/feeder module)
    • Low running costs & fuel consumption due to direct crusher drive & efficient plant controls
    • Fuel efficient direct drive system
    • Highly efficient, hydraulically operated self adjusting PT-Tech dry plate clutch, featuring PLC controlled "push button" start up sequence
    • Hydraulic live 2 deck pre-screening unit with bolt in cartridge style grizzly section and underscreen mesh.
    Options
    • Grizzly bars
    • Single pole/twin pole magnet
    • Radio remote control
    • Belt weigher
    • Electric refuelling pump
    • Hydraulic water pump
    • Product conveyor dust shroud
    • 800mm (2'6") wide hydraulically folding dirt conveyor
    • Plant lighting
    • Transport beam
    • Maintenance platform
    • Pre-screen media
    Specification Table
    XA750S
    Weight (Est) 74,500kgs (164,244lbs) incl. dirt conveyor & magnet
    Transport width 3.41m (11'2") with LHS walkway, without dirt conveyor
    Transport width 3.55m (11'8") with dirt conveyor fitted
    Transport length 17.9m (58'10")
    Transport height 4.17m (13'8") pre-cleaner removed
    Working width 3.87m (12'7") without dirt conveyor
    Working width 8.55m (28') with side conveyor deployed
    Working length 17.43m (57'2")
    Working height 5.44m (17'10")
