Trakpactor 260 / 260SR

PRODUCT TYPE: Impact Crusher

VENDOR: Powerscreen

CLICK HERE to download brochure
CLICK HERE to view video

DESCRIPTION

The Powerscreen® Trakpactor 260 and 260SR are part of our mobile impact crusher range have been designed for the recycling and demolition markets. Capable of processing a wide range of material at a high output, these plants are versatile, easy to operate and fuel efficient due to their direct drive system. Both plants offer users both excellent reduction and a high consistency of product shape alongside key features such as hydraulic overload protection.

The Powerscreen® Trakpactor 260SR features a post-screen system and recirculating conveyor allows oversize material to be passed back to the crusher for further sizing. A quick-detach single deck post-screen system allows the machine to convert to a standard Trakpactor 260 in minutes.

Features & Benefits
  • Output Potential: up to 250 tph (275 US tph)
  • Replaceable tine bar cartridge style grizzly feeder
  • Load management system to control feeder speed
  • Crusher chamber: Patented hydraulic overload protection and adjustment.
  • 4 bar rotor and twin apron design
  • Crusher speed variation and height controlled through user friendly PLC control system
  • Fully Independent under crusher vibrating pan feeder
  • Modular conveyor with raise/lower facility to aid clearance of rebar
  • Economical to operate with HFO clutch and highly fuel efficient direct drive system
  • Post screen system and recirculating conveyor (260SR )
Options
  • Full and half size chrome, martenistic, austenitic, and ceramic blow bars
  • Grizzly blanking mats
  • Single / twin pole magnet
  • Side conveyor
  • Under screen wire mesh
  • Electric re-fueling pump
  • Belt scale
  • Side dirt conveyor
  • Hot / cold climate oil kits
  • Hydraulic water pump
  • Radio remote control
  • Control panel positive
Specification Table
Trakpactor 260 Trakpactor 260SR
Weight 27,000kgs 59,525lbs) 33,950kgs (74,847lbs)
Transport width 2.5m (8'2") 3.0m (9'10")
Transport length 13.4m (43'10") 14.8 (48'6")
Transport height 3.2m (10'6") 3.2m (10'6")
Working width 4.0m (13'1") 5.5m (18')
Working length 13.4m (43'10") 15.8m (51'8")
Working height 3.6m (11'10") 3.86m (12'67")



* All information subject to machine configurations & specifications ordered.

** Powerscreen reserves the right to change specifications without prior notice.
