NH6020 Wheel Trommel

PRODUCT TYPE: Star Screen

VENDOR: Neuenhauser

CLICK HERE to download brochure
CLICK HERE to view video

DESCRIPTION

The Neuenhauser NH6020H trommel features a European spiral style drum which is interchangeable with most other manufactures.  The ripped belt drive avoid belt slippage on the large 15yd3 hopper.  With a water cooled engine and turbo loaded with air to air load cooling this trommel can work in even the harshest conditions.

NH6020 Trommel is designed and built specifically for the organics and recycling industries.

    Features & Benefits
    • Direct Drive
    • European spiral style drum
    • Max feed size 6”
    • High capacity 350yd3/hr (depending on material*)
    • Hydraulic folding discharge conveyor
    • Drum interchangeable with other manufacturers
    • Full access doors for drum removal
    • Diesel hydraulic drive
    • Reversible radiator fan
    • Electronic engine control and monitory LCD display
    • Extra wide fines collection conveyor
    • Ripped belt drive on feed hopper
    • 15yd3 hopper capacity
    • Optional Starscreen insert
      Specification Table
      NH6020 Wheel
      Weight 52,000lbs
      Transport width 8’ 4”
      Transport length 43’
      Transport height 13’ 1”
      Working width 20’
      Working length
      Working height 13’ 1”
      Drum size
      18' x 6' 7"

      * All information subject to machine configurations & specifications ordered.

      ** Neuenhauser reserves the right to change specifications without prior notice.
