Powerscreen 1300 Maxtrak Cone Crusher

PRODUCT TYPE: Cone Crusher

VENDOR: Powerscreen

CLICK HERE to download brochure
CLICK HERE to view video


The Powerscreen® 1300 Maxtrak is a medium to large sized track mobile cone crusher which is ideally suited to secondary applications such as taking an "all in-feed" from a primary crusher. Based around the 1300 Automax® cone crusher, the plant excels in the production of sub-base or aggregates, providing excellent cubicity, throughput and reduction ratios.

    Features & Benefits
    • Output Potential: up to 350 tph (386 US tph)
    • Renowned Automax® crusher technology
    • Accepts all in clean feed
    • Excellent product shape
    • High reduction ratio
    • Hydraulic crusher setting
    • Cone overload protection
    • Heavy duty chassis and track frame
    • Metal detector
    • Cone feed box level control to maintain choke feeding
    • Dust suppression system
    • Economical to operate with a highly fuel efficient direct drive system
    • Fitted with Powerscreen Pulse Telematics system
    • Feed hopper extension plates
    • Feed hopper level sensor
    • Concave: Autosand, medium coarse
    • Product conveyor belt weigher
    • Electric refuelling pump
    • Hydraulic water pump
    • Urea refuelling pump
    • Radio remote control
    Specification Table
    1300 Maxtrak
    Weight 47,880kgs (105,557lbs)
    Transport width 3m (9'10")
    Transport length 15.35m (50'4")
    Transport height 3.85m (12'8")
    Working width 3.85m (12'8")
    Working length 15.5m (50'10")
    Working height 4.7m (15'5")


    * All information subject to machine configurations & specifications ordered.

    ** Powerscreen reserves the right to change specifications without prior notice.
