Warrior 2400

Name: Warrior 2400
Brand: Powerscreen
Availability: InStock

PRODUCT TYPE: Scalper Screener

VENDOR: Powerscreen

Add To Compare Added To Compare

CLICK HERE to download brochure

CLICK HERE to view video

DESCRIPTION
Specially designed for large scale operators in the quarrying and mining sectors, the Powerscreen® Warrior 2400 is capable of handling larger feed sizes and throughputs. It features a heavy duty incline screen with a high amplitude triple shaft drive mechanism, lending it to screening, scalping, 2 or 3 way splitting and stockpiling materials like aggregates, topsoil, coal, construction, demolition waste and iron ore.

User benefits include a slide out tail conveyor facilitiy to aid media access and a load sensing collection conveyor circuit to avoid blockages.

Features & Benefits

Output potential up to 800 tph (881 US tph)
Heavy duty, incline belt feeder with hydraulic folding hopper sides
Hydraulic load sensing on under screen conveyor circuit
Aggressive heavy duty triple shaft screen, with adjustable stroke angle
Jack up screen facility to aid mesh changes
Screen walkway and access steps
Screen media interchangeable with H range products
Jack up legs for screen levelling
Hydraulic folding conveyors with excellent stockpiling capacity
Engine protection shut down

Options

Hopper extensions
High capacity incline apron feeder
Wide range of screen media
Screen chain blanket
Auto lubrication system
2 or 3 way split configurations
Roll-in bogie (tri-axle)
Radio controlled tracking
Dual power (additional electric hydraulic drive)
Dust suppression

Specification Table

	2 Way Split	3 Way Split
Weight	43,000kgs (94,798lbs)	45000kgs (99,208lbs)
Transport width	3.0m (9'10")	3.0m (9'10")
Transport length	17.19m (56'5")	17.33m (56'10")
Transport height	3.6m (11'10")	3.6m (11'10")
Working width	9.58m (31'5")	15.33m (50'4")
Working length	18.34m (60'2")	18.5m (60'8")
Working height	4.88m (16')	5.2m (17'1")
Screen unit	6.1m x 1.8m (20' x 6')
Screenbox is a triple shaft
